AB-CLASS STEREO AMPLIFIER
HCP 2 is a stereo, 400W car audio amplifier, designed to expand or modify with maximum easiness the factory system: featuring pre-amplified (Pre-In) inputs as well as high-level (Speaker-In) inputs, for connection with any head units.
All the Hertz Compact Power amplifiers are assembled with high-quality components and feature a complete and by-passable crossover system. The dissipation system is optimized with the heat being transferred to the heat sink and then dissipated through the sides of the amplifier.
With HCP 2 high power systems can be realized: settable both in mono, to drive the subwoofer, and together with another amplifier, for more complex systems; it also features a Bass Boost filters (0 ÷ 12 dB) to enhance low frequencies.
Specifications
| Channel mode | 2 - 1 |
| Output Power (RMS) @ 14.4 VDC | 2 Ch: 65 W x 2 (4Ω) 2 Ch: 100 W x 2 (2Ω) 1 Ch: 200 W x 1 (4Ω) |
| Filters Bypass Hi-Pass Lo-Pass Band-Pass | Yes 80 Hz @ 12 dB/Oct. 50 - |
| Distortion - THD (100Hz @ 4Ω) | 0.01% |
| S/N Ratio (A weighted @ 1V) | 103 dB |
| Damping factor (100Hz @ 4Ω) | 200 |
| Size W x D x H mm | 215 x 190 x 50 |
